Micropower Operational Amplifier for GreenPAK™
ページセクションへ移動：
Back to top
ECADモデルを調べる
概要
Description
The SLG88103 is a wide voltage range, 375 nA Dual Channel CMOS Input Operational Amplifier capable of rail-to-rail input and output operation. Each Amplifier can be individually powered down.
特長
- Supply Voltage: 1.71 V to 5.5 V
- Low Quiescent Current: 375 nA per Amplifier (typ)
- Rail to Rail Input/Output
- Low Offset Voltage: ±200 µV (typ)
- Low Offset Drift: 1 µV/˚C (typ)
- DC Precision:
- PSRR: 115 dB
- CMRR: 100 dB
- AOL: 120 dB
- Zero-Crossover
- Gain-Bandwidth Product: 10 kHz (typ)
- Industrial Temperature Range: -40 ˚C to 85 ˚C
アプリケーション
アプリケーション
- Battery-Powered Devices
- Portable Devices
- Wearable Products
- Gas Sensors
- Pressure Sensors
- Medical Monitors
- Smoke Detectors
- Active RFID Reader
- Energy Harvester
設計・開発
ソフトウェア／ツール
ボード＆キット
ボード＆キット
SLG88103V Evaluation Board
The SLG88103V-EVB board evaluates the SLG88103V Micropower Operational Amplifier for GreenPAK™.
