High Voltage GreenFET Load Switch
Jump to Page Section:
Overview
Description
The SLG59H1005V is a high‑performance, self‑powered 50 mΩ NMOS load switch with back-to-back reverse‑current blocking designed for all 4.5 to 22 V power rails up to 3 A. Using a proprietary MOSFET design, the SLG59H1005V achieves a stable 50 mΩ RDSON across a wide input voltage range. In combining novel FET design and copper pillar interconnects, the SLG59H1005V package also exhibits a low thermal resistance for high‑current operation. Designed to operate over a -40 °C to 85 °C range, the SLG59H1005V is available in a low thermal resistance, RoHS‑compliant, 1.6 mm x 3.0 mm STQFN package.
Features
- Optimized for Telecommunications Equipment, High‑performance Enterprise Computing, Motor Drives
- 50 mΩ RDSON
- Maximum Continuous Current: 3 A
- Wide Operating Supply Voltage: 4.5 V to 22 V
- Back-to-Back FET Reverse-current Blocking, when OFF
- Automatic nFET SOA Protection
- 4-Level, Pin-selectable VIN Overvoltage Lockout
- Capacitor-adjustable Inrush Current Control
- Two stage Current Limit Protection:
- Resistor-adjustable Active Current Limit
- Fixed 0.5 A Short-circuit Current Limit
- ON-OFF Control: Active HIGH
Applications
Applications
- Power-Rail Switching
- Multifunction Printers
- Large-format Copiers
- Telecommunications Equipment
- High-performance Computing 4.5 V and 22 V Point‑of‑Load Power Distribution
- Motor Drives
Documentation
| Document title | Document type
|
Date Date | |
|---|---|---|---|
| PDF 1.85 MB | Datasheet | ||
| PDF 911 KB | Application Note | ||
| PDF 1.40 MB | Application Note | ||
| PDF 85 KB | Application Note | ||
| PDF 3.47 MB | Guide | ||
| PDF 5.26 MB | Overview | ||
6 items
|
|||
Design & Development
Boards & Kits
Boards & Kits
SLG59H1005V Evaluation Board
The SLG59H1005V-EVB board evaluates the SLG59H1005V High Voltage GreenFET, Load Switch.
