Overview

The R2A20114B continuous conduction mode (CCM), power factor correction (PFC) IC from Renesas provides interleaved operation at high power levels along with inexpensive anti-noise measures, enabling manufacturers to design low-cost air conditioner models that combine a high power factor and high efficiency.

Power Supply for Air Conditioner
Power Supply for Air Conditioner

Related Products

Photocoupler Lineup

Block Semiconductor Device Recommended Products Features
Indoor-Outdoor Unit
Signal I/F		 General-purpose
photocouplers		 PS23xx Series
PS27xx Series
PS28xx Series 		High isolation voltage (5kVrms), 4-pin LSOP, Ta = 115 °C
High isolation voltage (3.75kVrms), 4-pin SOP, Ta = 110 °C
High isolation voltage (2.5kVrms), 4-pin SSOP, Ta = 110 °C
High-speed
photocouplers		 PS93xx Series (SDIP)
PS95xx Series (8-pin DIP) 		Digital output
~15Mbps
Low supply current
For TRIAC Control General-purpose
photocouplers		 PS23xx Series
PS27xx Series
PS28xx Series 		High insulation high isolation voltage (5kVrms), 4-pin LSOP, Ta = 115 °C
High isolation voltage (3.75kVrms), 4-pin SOP, Ta = 110 °C
High isolation voltage (2.5kVrms), 4-pin SSOP, Ta = 110 °C
Inverter Circuit Photocouplers for
IGBT drive		 PS93xx Series (SDIP)
PS95xx Series (8-pin DIP) 		High isolation voltage (5kV ~ 7.5kVrms)
0.6 ~ 2.5A output
High CMR (CMR ≥ 50kV/μs)

Others

Block Semiconductor Device Recommended Products Features
Outdoor Unit Shunt regulator μPC1093,μPC1943 /1944 Optimal for output voltage detection of outdoor unit power supply
MCU Peripherals Sensor signal amplifier
CMOS op amp		 μPC4742, μPC4744 High slew rate
